manual stacker PL 1600 ST, I43161

1 200,00 € + KM

Manual stacker with robust construction.
Equipped with foot pump.
Width 850 mm and length 1980 mm.
Lifting speed 22 mm/lift.
Width of forks 550 mm.
Length of forks 1150 mm.
Lifting capacity 1000 kg.
Lifting height 85-1600 mm.
Height of mast 1980 mm.
Conveyor radius 1380 mm.
Guide wheels nylon, Ø 180 x 50 mm, equipped with brake.
Fork wheels, nylon, Ø 74 x 55 mm.
The weight is 220 kg.

Add to cart

Quick view

WS10S-3300 tuner, I45106

4 850,00 € + KM

Capacity Kg: 1000
Min fork height mm: 90
Lifting height mm: 3300
Centre of gravity separation: 600
Min support height: 2185
Max support height: 3800
Total width mm: 820
Total lenght mm: 1770
Free lift mm: 0
Fork width mm: 160
Fork length mm: 1150
Driving speed without/with load km/h: 4/3.5
Lifting speed without/with load mm/s: 134/95
Lowering speed without/with load mm/s: 94/130
Swing radius mm: 1430
Electronics: Curtis
Drive motor: 0,65 kW
Lifting motor: 1,5 kW
Truck battery: 75Ah/12V x 2
Charger: Built-in
Fork wheel mm: Polyutethane 78 x 93
Drive wheel mm: 220 x 70
Gradient capacity without/with load: 10/3 degrees
Brake: Electromagnetic
Speed regulation: Electronic impulse
Weight kg incl. battery: 570
Mast type: Duplex
